If you are looking to getting into chainsaw carving please read this post on arbtalk here.



Chainsaw carving is NOT like standard chainsaw use – ie. you can’t simply strap on a carving bar and do carving – we broke our first carving bar and shortly after broke the chainsaw… please learn by our mistakes! We did not follow the below..



  1. Chain is SLACK – no where near as tight as a standard bar, it should be hanging off the underside of the bar
  2. R7 bars running 1/4 .043 are SUPER delicate and only used for very fine detail work
  3. Carving is mainly done with the saw at half throttle [or thereabouts] – very different from standard work where most cuts are with full throttle
  4. Carving bars take longer to bed in – run them gently and ensure they don’t get hot for the first couple of tanks [which means carve for a minute – rest a minute – carve for a minute = rest for a minute… ]
  5. Take the heels of the cutter teeth to reduce friction [Stihl 3661-13RMS already has this feature] but click here to see more on this.











You want more info on carving? Then have a look at these pages here… But grab a cuppa and do this when you have time – Carving like chainsaw milling is an art, a skill and you will not simply be able to spend 20 minutes to buy your bits then get cracking [or you can but you will break something at some point..]



If the bar is Sugihara and starts BN6 [for Cannon it is C1] this is a UNIVERSAL mount and will fit most small saws under 40cc.






[STIHL4] CCQ-S1-24-50 Cannon Carving Quarter Tip 24″ [61cm] 3/8 Lo Pro .050 82 drive links or .325 .050 92 drive links or 1/4 .050 116 drive links

$331.13

Add to
Stock 2
Part Number CCQ-S1-24-50
Weight 591g
Part Number CCQ-S1-24-50 Categories: ,
Durability
Stiffness
Cut speed

Made from formulated, cold rolled, annealed, heat treated, surface ground, and stress relieved steel. This provides the best possible characteristics of wear resistance, strength, durability, straightness and elasticity.

The Cannon SuperBar power plus profile maximizes cutting power and chain speed while reducing damage from loose chain.

A precision ground groove to within .002″ means straighter cuts. Each groove is individually centered for even rail wear and superior durability. This increases rail strength and reduces damage from pinches. Also, if the chain rides exactly square to the rail, the result is smoother and straighter cutting. Milling marks, commonly found in the competitions bars, are eliminated. Thus, the groove is tighter and sloppy chain travel occurs much less.

Cannon SuperBars have flame tempered rails that are hardened to 5 points more than the tie straps on the chain for much longer bar life. This hardening penetrates deep to allow for multiple bar repairs and rebuilds. With the chain running straight and true, the result is a faster and smoother cut.


Product Highlights

    • Available in .325″, .375″ or .404″ pitch single rivet sprocket noses
    • Motor mounts available for most makes and models of chainsaws
    • Precision squared and flame hardened rails
    • Stress relieved heel prevents cracking and reduces vibration
    • Available in .050, .058 or .063 gauge
    • Available in lengths from 16 to 84 inches
    • Precision ground groove

‘Cannon bars are awesome. I wish I’d have brought this small one much sooner’  Samantha Possinger

‘Well – they always seem to last the longest. Cannon are the best. This one’s going on my Stihl MS201’ Ant Beetlestone

‘All round reliability’  Lorraine Botterill

‘I’m currently replacing all my bars for Cannon bars…in my opinion they’re the best’ Rolande Urwin

Additional information

Weight 591 g
